XJ-D148 6S 5A BMS Common Port with Balance NTC Battery Protection Board
XJ-D148 BMS, 6S 5A, common port, with passive balance and NTC, support LifePO4, Li-ion battery.
|
Product Name
|
6S Lithium Battery BMS
|
|
Size
|
Length 105mm * Width 17mm * Thickness 5mm
|
|
Series
|
6S |
|
Current
|
5A
|
|
Voltage
|
19.2V / 22.2V / 25.2V
|
|
Cell Type
|
LifePO4/NMC/Lithium
|
|
Function
|
Over charge protection, Over discharge protection, Over current protection, Short-circuit protection, Balance function, NTC Temperature sensor function, Electrostatic protection, Dust Protection, Moisture Protection
|
|
Warranty
|
24 Months
|
| Item | Symbol | Inspection standard | Unit | |||
| Min | Typical | Max | ||||
| Overcharge protection | Overcharge detection voltage | VDET1 | 4.2 | 4.25 | 4.3 | V |
| Overcharge detection delay time | tVDET1 | 500 | 1000 | 1500 | ms | |
| Overcharge discharge voltage | VREL1 | 4 | 4.05 | 4.1 | V | |
| Over-discharge protection | Over-discharge detection voltage | VDET2 | 2.6 | 2.7 | 2.8 | V |
| Over-discharge detection delay time | tVDET2 | 500 | 1000 | 1500 | ms | |
| Over-discharge discharge voltage | VREL2 | 2.9 | 3 | 3.1 | V | |
| Overcurrent protection | Overcurrent detection voltage | VDET3 | 0.09 | 0.1 | 0.11 | V |
| Overcurrent protection current | IDP | 7 | 10 | 15 | A | |
| Detection delay time | tVDET3 | 50 | 100 | 150 | ms | |
| Short-circuit protection | Detection delay time | TSHORT | 100 | 300 | 500 | μS |
| Conditions for lifting protection | Disconnect the external short-circuit load or charge and restore | |||||
| Internal resistance | Main circuit on-state resistor | IPWN | 50 | mΩ | ||
| Current consumption | It usually consumes current when in operation | IDD | 50 | μA | ||
| Static current | It consumes current during hibernation | IPWN | 4 | 6 | μA | |
| Equalization | Equalization charging voltage | VOC | 4.15 | 4.2 | 4.25 | V |
| Equalization charging current | 20 | 40 | 60 | mA | ||
