    XJ-D087 4S 12V 75A BMS for LifePO4 Li-ion Battery Management System with Balance NTC

    This model XJ-D087 4S 75A BMS, with balance, double NTC. Passive balance, balance current 30-50mA. Common port, the charge current and the discharge current is the same, continuous working current range 30A-75A.

    With connector, wire welding, easy to connect to the battery pack.

    Application to portable energy storage.

    • Model XJ-D087
    • Series 4S
    • Current 75A
    • Voltage 12V
    • Cell Type NMC/LFP/Lithium
    • Function Over charge protection, Over discharge protection, Over current protection, Short-circuit protection, Balance function, NTC Temperature sensor function, Electrostatic protection, Dust Protection, Moisture Protection
    • Warranty 24 Months
    • Board Size 151*39*6MM
    • OEM/ODM Acceptable
    • Application Portable energy storage
    Contact us
    Product Data
    Product Description

    XJ-D087 BMS, 4S 12V 75A, with passive balance, balance current 30-50mA, common port, wire welding with connecter.

    Product Name
    4S 12V 75A BMS battery protection board
    Series
    4S
    Working Current
    75A
    Input & Output
    Same Port
    Cell Type
    LifePO4, Li-ion battery
    Function
    Over charge protection, Over discharge protection, Over current protection, Short-circuit protection, Electrostatic protection, Balance, NTC Temp Protection, Dust Protection, Moisture Protection
    Warranty
    24 Months
