XJ-D082 4S 12V 5A/10A BMS Common Port Battery Protection Board
XJ-D082 4S 12.8V/16.8V 5A/10A BMS, common port, for LifePO4, Li-ion Battery.
|
Product Name
|
4S 10A BMS battery protection board
|
|
Series
|
4S
|
|
Working Current
|
5A/10A
|
|
Input & Output
|
Same Port
|
|
Cell Type
|
LifePO4, Li-ion battery
|
|
Function
|
Over charge protection, Over discharge protection, Over current protection, Short-circuit protection, Electrostatic protection, Dust Protection, Moisture Protection
|
|
Warranty
|
24 Months
|
| Item (the spec of 4S 10A 4.2V Battery) | Min | Typical | Max | Unit |
| Battery pack charging voltage | 16.8 | 17 | V | |
| Charging MOS withstand voltage | 30 | V | ||
| Discharging MOS withstand voltage | 30 | V | ||
| Single cell overcharge detection voltage | 4.2 | 4.25 | 4.3 | V |
| Overcharge recovery voltage | 4.1 | 4.15 | 4.2 | V |
| Overcharge detection delay | 500 | 1000 | 1500 | mS |
| Single cell over-discharge detection voltage | 2.6 | 2.7 | 2.8 | V |
| Over-discharge recovery voltage | 2.9 | 3 | 3.1 | V |
| Over-discharge detection delay | 500 | 1000 | 1500 | mS |
| Battery pack continuous discharge current | 10 | A | ||
| Battery pack continuous charging current | 10 | A | ||
| Discharge overcurrent protection | 28 | 33 | 38 | A |
| Overcurrent protection delay | 500 | 1000 | 1500 | mS |
| Self-consumption | 30 | 40 | uA | |
| Charging protection temperature | /℃. | |||
| Discharge protection temperature | /℃. | |||
| Output short circuit/over-discharge/overcurrent protection recovery | Automatic recovery after removing load following short circuit/over-discharge/over-current protection | |||
| Short circuit protection delay | 100 | 300 | 600 | uS |
| Normal operating state B-to-P- internal resistance | 40 | mΩ | ||
| Continuous 4A output current maximum temperature rise | 40 | ℃ | ||
