4S BMS
XJ-D032 4S 12V 15A BMS Common Port LifePO4 Li-ion Lithium Battery BMS
XJ-D032 4S 12.8V/16.8V 15A BMS, common port, for LifePO4, Li-ion battery BMS.
|
Product Name
|
4S 12V 15A Lithium Battery BMS
|
|
Size
|
Length 69mm * Width 60mm * Thickness 6.5mm
|
|
Series
|
4S
|
|
Current
|
15A
|
|
Voltage
|
12.8V / 16.8V
|
|
Cell Type
|
LifePO4/NMC/Lithium
|
|
Function
|
Over charge protection, Over discharge protection, Over current protection, Short-circuit protection, Electrostatic protection, Dust Protection, Moisture Protection
|
|
Warranty
|
24 Months
|
| Items | Min | Typical | Max | Unit |
| Battery pack charging voltage | 15.4 | 15.6 | V | |
| Charging MOS withstand voltage | 30 | V | ||
| Discharging MOS withstand voltage | 30 | V | ||
| Overcharge detection voltage | 15.3 | 15.4 | 15.5 | V |
| Overcharge detection delay | 500 | 1000 | 1500 | mS |
| Overdischarge detection voltage | 7.1 | 7.2 | 7.3 | V |
| Overdischarge detection delay | 50 | 100 | 200 | mS |
| Battery pack continuous discharging current | 15 | A | ||
| Battery pack continuous charging current | 15 | A | ||
| Self-discharge | 30 | 40 | uA | |
| Discharge temperature protection | 95±5℃ | |||
| Output short circuit/overdischarge/overcurrent protection recovery | Automatic recovery after removing load following short circuit/over-discharge/over-current protection | |||
| Normal operating state B to P internal resistance | 30 | mΩ | ||
| Maximum temperature rise with 15A output current | 40 | ℃ | ||
