6S BMS
XJ-D019 6S 5A/10A 25V BMS Same Port BMS LifePO4/NMC/Lithium Battery Protection
6S 5A/10A BMS
| Item | Min | Typical | Max | Unit |
| Battery pack charging voltage | 25.2 | 25.5 | V | |
| Charging MOS withstand voltage value | 65 | V | ||
| Discharge MOS withstand voltage value | 65 | V | ||
| Single-cell overcharge detection voltage | 4.2 | 4.25 | 4.3 | V |
| Overcharge recovery voltage | 4.1 | 4.15 | 4.2 | V |
| Overcharge detection delay | 500 | 1000 | 1500 | mS |
| Single-section over-discharge detection voltage | 2.6 | 2.7 | 2.8 | V |
| Over-discharge recovery voltage | 2.9 | 3 | 3.1 | V |
| Over-discharge detection delay | 500 | 1000 | 1500 | mS |
| Continuous discharge current of the battery pack | 10 | A | ||
| Continuous charging current of the battery pack | 10 | A | ||
| Discharge overcurrent protection | 15 | 20 | 25 | A |
| Overcurrent protection delay | 500 | 1000 | 1500 | mS |
| Self-consumption | 30 | 40 | uA | |
| Balanced current | / | / | / | mA |
| Charging temperature protection | /℃. | |||
| Discharge temperature protection | /℃ | |||
| Output short circuit/overdischarge/overcurrent protection recovery | The load automatically recovers after the short-circuit/over-discharge/over-current protection is removed | |||
| Short-circuit protection delay | 100 | 300 | 600 | uS |
| Internal resistance from B- to P- under normal working conditions | 30 | mΩ | ||
| The maximum temperature rise with a continuous output current of 10A | 40 | ℃ | ||
