XJ-B016 10S 42V 20A 25A BMS LifePO4 Battery for E-scooters
10S 36V 25A BMS for electric scooters, e-bikes, with NTC temperature sensors, seperate port charge 3A discharge 25A
|
Model
|
XJ-B016
|
|
Series
|
10S
|
|
Charge Current
|
3A
|
|
Discharge Current
|
25A
|
|
Voltage
|
42V
|
|
Battery
|
LifePO4/NMC/Li-ion battery
|
|
Application
|
Electric Scooter/E-bikes
|
|
Warranty
|
2 Years
|
|
OEM&ODM
|
YES
|
| Item (the spec of 10S 25A) | Min | Typical | Max | Unit |
| Battery pack charging voltage | 42 | 42.5 | V | |
| The withstand voltage of the charging MOS | 85 | V | ||
| Discharge MOS withstand voltage value | 85 | V | ||
| Single-cell overcharge detection voltage | 4.2 | 4.25 | 4.3 | V |
| Overcharge recovery voltage | 4.05 | 4.1 | 4.15 | V |
| Overcharge detection delay | 500 | 1000 | 1500 | mS |
| Single-section overdischarge detection voltage | 2.6 | 2.7 | 2.8 | V |
| Overdischarge recovery voltage | 2.9 | 3 | 3.1 | V |
| Over-discharge detection delay | 500 | 1000 | 1500 | mS |
| Continuous discharge current of the battery pack | 25 | A | ||
| Continuous charging current of the battery pack | 3 | A | ||
| Discharge overcurrent protection | 28 | 36 | 44 | A |
| Overcurrent protection delay | 270 | 370 | 470 | mS |
| Self-consumption | 30 | 50 | uA | |
| Equilibrium current | / | / | / | mA |
| Charging temperature protection | High temperature: 50±5℃, low temperature: -10±5℃. | |||
| Discharge temperature protection | High temperature: 70±5℃ | |||
| Output short circuit/overdischarge/overcurrent protection recovery | After short-circuit/overdischarge/overcurrent protection, the load is removed and it automatically recovers | |||
| Short-circuit protection delay | 100 | 300 | 600 | uS |
| Under normal working conditions, the internal resistance is B- to P- | 10 | mΩ | ||
| Maximum temperature rise with a continuous output current of 25A | 40 | ℃ | ||
